Why the ICARUS Lite?
Using the Typhoon from Dyze Design, you have a selection between high-flow and high-detail 3D printing.
Extrusion System
For accuracy and safety, high-precision ballscrews are used on the X,Y, and Z axis of the entire machine. You won't find a belt on this machine. All of this, combined with USA Made servo motors from Teknic on all three axis, ensure precise motion movement.
Linear Motion
Auto-Calibration
Developed in house, before the start of every print the printer will use the nozzle to auto-calibrate the printer before a single layer is ever laid down on the print bed.
Technical requirements characteristics:
Machine size (W,D,H): 26"x30"x49"
Weight: -180lbs
Print area: 305x305x610mm
Motora: USA made Servo Motors
Motion: TBI precision ballscrews
Extrusion: Typhoon (FDM)
Print surfaces: G10/FR4
Print plate: Magnetic
Build plate: 3/8" MIC-6
Max print temperature: 450C
Max bed temperature: 120C
Temperature probe(s): PT100
Bed leveling: Three Z Axis Tilt & Mesh
Electronics: PROTEOR Print Software
Machine power: 110VAC
Touchscreen: 7in touchscreen
Connectivity: WIFI, Ethernet, USB
Slicer: Simplify 3D and PrusaSlicer
